    10km 20km 10G SFP+ Optical Transceiver LR SFP Single Mode LC Receptacle

    Ask Lasest Price
    Brand Name : sunwise
    Model Number : SFP-10G
    Certification : ROHS CE FCC
    Price : Negotiable
    Delivery Time : jumper 3 ~ 7 days; fiber optic cable and equipment 7 ~ 15 days
    Payment Terms : Western union,T/T,PayPal
    Supply Ability : 1 million km / month for fiber optic cables; 200,000 pcs / month for patch cords;100,000 PCS / month for equipment
    • Product Details
    • Company Profile

    10km 20km 10G SFP+ Optical Transceiver LR SFP Single Mode LC Receptacle

    10km 20km 10G SFP+ Optical Transceiver LR SFP Single Mode LC Receptacle


    Product Description

    This Bi-directional 10Gb/s (SFP+) transceivers optical modules are compliant with the current SFP+ Multi-Source Agreement (MSA) Specification, comply with 10GBASE-LR/LW Ethernet, SONET OC-192 / SDH and 10G Fibre Channel 1200-SM-LL-L. Digital diagnostics functions are available via a 2-wire serial interface, as specified in the SFP+ MSA.


    PRODUCT FEATURES

    Up to 10.7Gbps Data Links

    Single Mode LC Receptacle

    Up to 60km transmission on SMF

    Power dissipation<1.5W

    1270nm DFB laser and APD receiver

    2-wire interface with integrated Digital Diagnostic monitoring

    EEPROM with Serial ID Functionality

    Compliant with SFP+ MSA with duplex LC connector

    Single + 3.3V Power Supply and LVTTL Logic

    Case operating temperature: -5ºC~+70ºC


    Application

    • SDH STM-1, S-1.1,L-1.1, L-1.2

    • SONET OC-3 IR1,LR1,LR2

    • Other optical links


    STANDARD

    Compliant with SFF-8472 SFP+ MSA.

    Compliant to SFP+ SFF-8431 and SFF-8432.

    RoHS Compliant.


    Working ParameterSymbolMin.TypicalMax.Unit
    Storage TemperatureTS-40+85°C
    Supply VoltageVCCT, R-0.54V
    Relative HumidityRH085%
    Case operating TemperatureTC-5+70°C
    Supply CurrentICC400mA
    Power DissipationPD1.5W

    • Supports 9.95Gb/s to 11.3Gb/s bit rates
    • Hot-pluggable SFP+ footprint
    • Single LC for Bi-directional Transmission
    • Maximum link length of 20km
    • Built-in 1270/1330 WDM Filter
    • Uncooled 1270nm or 1330nm DFB Laser.
    • Power dissipation <1.5W
    • No Reference Clock required
    • Built-in digital diagnostic functions
    • Temperature range 0°C to 70°C
    • Low EMI and excellent ESD protection
